Above the Curve

Curved glass can create a wow-effect like nothing else, bringing an aesthetic edge to modern buildings and homes. All our curved glass is processed in-house, where our strict quality-control procedures and full facility control ensure every curve is perfectly to spec.

Sizing

ThicknessMinimum Curve RadiusMaximum WidthMaximum Height
6 mm (0'1")1,200 mm (4'0")2,700 mm (8'11")4,600 mm (15'2")
8 mm (0'1")1,200 mm (4'0")2,700 mm (8'11")4,600 mm (15'2")
10 mm (0'1")1,200 mm (4'0")2,700 mm (8'11")4,600 mm (15'2")
12 mm (0'1")1,500 mm (5'0")2,700 mm (8'11")4,600 mm (15'2")
15 mm (0'1")3,000 mm (9'11")2,200 mm (7'3")3,900 mm (12'10")
19 mm (0'1")3,000 mm (9'11")2,000 mm (6'7")3,900 mm (12'10")

Options

  • Toughened, laminated and insulated possibilities to meet performance and safety requirements
  • Double-glazed, triple-glazed
  • Low-E and solar control
  • Available for clear, tinted, reflective, digitally printed, low-iron, high-performance and spandrel glass
  • Available with holes, notches, cut-outs, polished and ground edges, and sandblast designs
Download Technical Specs
  • Sorry, no Technical Specs are available currently.
    Please check again soon or contact our team
